Airstream RV Atlas Motor Home Class B+ - Diesel

1 of 15

The Airstream Atlas is setting a new standard for those who want travel in style, convenience and comfort. The Atlas is built on a Mercedes-Benz Sprinter van chassis and features Air Ride Suspension, which accounts for bumps in the road and wind resistance and adjusts itself so you can get a smooth ride where ever you roam.


You'll appreciate the safety standards that have been added to protect your family while on the road, including a Fusion infotainment system with Garmin navigation and lane guidance, collision prevention assist, lane keeping assist, rear and side view cameras, and the most airbags available from Mercedes-Benz. From the power slide out Murphy bed, to the residential style bathroom, you'll feel comfort at every turn.


Come see why we're calling the Airstream Atlas our most luxurious touring coach to date!

Atlas Features:

Standard Features (2020)



  • 1.1 cu. ft. Convection Microwave
  • Mercedes-Benz® Sprinter 3500 Chassis
  • Mercedes-Benz® 3.0L V6 Turbo Diesel
  • BlueTEC SCR Technology, 50 State – EPA/CARB Standards
  • 188 HP / 325 lbs torque
  • 5 Speed Automatic
  • Axle Ratio, 3.92
  • Wheelbase, 170″
  • MPG*, 16-18 Estimated Highway
  • Mercedes-Benz® Adaptive ESP® (Electronic Stability Program)
  • GVWR/GCWR, 11,030 lbs/15,250 lbs
  • Mercedes-Benz® Hitch, 7 Pin Trailer Plug, Brake Control Pre-wired
  • Tow Capacity** Up to 5,000 lbs
  • Mercedes-Benz® Trailer Stability Assist System
  • Overall Length 24′ 9″
  • Overall Height 10′ 6″ (including A/C)
  • Overall Width 8′ 3″
  • Interior Height/Width, 6′ 6″ / 7′ 4.5″
  • Tank Capacities, 23 gals (Fresh), 31 gals (Gray), 23 gals (Black)
  • LPG, 9.76 gals (41.38 lbs) 80% fill
  • Diesel Fuel, 26.4 gals
  • 15,000 BTU Quietstream™ Ducted with Heat Pump
  • Furnace 16,000 BTU
  • 60,000 BTU On-Demand Continuous Flow water heater
  • Fresh, Gray & Black Tanks (12 volt)
  • Refrigerator & Freezer, 9.1 cu. ft. (12 volt)
  • 2 Burner with Integrated Cover
  • LP Gas Detector, Smoke and CO2 Alarm, Fire Extinguisher, First Aid Kit
  • Macerator Pump System w/Electric Retract
  • Omni Directional In-motion VHF/UHF
  • Cable TV Outlets/Hook-ups
  • Pre-wired for Satellite Dish
  • Touch Screen/Touch Pad Electronic Controls with Energy Management System
  • 50 amp Multi-stage Charger, 1,000 Watt Pure Sine Inverter
  • 3.2 kW (Diesel)  generator with Remote Start
  • Batteries (Coach), 2 – 12 Volt Deep Cycle Maintenance Free Group 24 AGMs
  • Shore Power, 30 amp/110 Volt Service
  • Solar Power, 300 Watt Solar System
  • 24/7 365 Roadside Assistance
  • Airstream Warranty***3 Years/36,000 Miles
  • Mercedes-Benz® Warranty*** 3 Years/36,000 Miles
  • Mercedes-Benz® Engine Warranty***5 Years/100,000 Miles
  • (Unit Base Weight) 10,045 lbs
  • (Net Carrying Capacity) 985 lbs


  • Advanced Navigation with RV Specific Warnings & Instructions
  • Collision Prevention Assist
  • Fire Extinguisher
  • Four Seat-Belt Positions
  • High Mounted Third Brake Light
  • Lane Keeping Assist
  • Multiple Safety Impact Air Bags
  • Rain Sensing Windshield Wipers
  • Rear Camera Assist with Always-On Viewing & Adjustable Angle
  • Side Camera Assist Integrated in Side Mirrors
  • Smoke, CO2 & LPG Detectors


  • 110V Outlet, HDMI & Coaxial Output
  • Air Ride Suspension
  • Alcoa® DuraBright Aluminum Wheels
  • BASF Metallic OE Paint with Cut & Buff Finish
  • Bi-Xenon Headlights with Washer System
  • Chrome Package (body line trim, grill, license plate holder)
  • Exterior Shower with Hot & Cold Water
  • Fog Lamps
  • Frameless Radius-Corner Tilt-Open Windows
  • Front Lower Spoiler
  • Heated Windshield
  • Hidden Hitch Cover Rear Bumper
  • Hidden Retracting Screen Door
  • LED Patio & Awning Lighting
  • LED Undercarriage Lights with Dimmer
  • LP Accessory Hook-up (Grill)
  • Mercedes-Benz® OE Sprinter Tail Lights
  • Power Armless Awning with Auto-Retract
  • Power Entry Step with Hidden Design
  • Power Heated Mirrors
  • Power Stabilizer Jacks
  • Remote Locking Storage Doors with Hidden Latches
  • Storage Compartments with LED Motion Lights


  • Custom Carpet Floor Mat
  • Entry Door Lighting
  • Heated Swivel Driver/Passenger Seats
  • In-Dash Maintenance Monitoring System
  • Locking Glove Box
  • Multifunctional Steering Wheel
  • Overhead Map Lights
  • Privacy Shades
  • Rear & Side View Camera Monitor
  • Tilt & Telescopic Steering Wheel
  • Touch Screen NAV/SAT Radio/DVD System (8″)

Main Cabin

  • Adjustable LED Lighting
  • Angel White Overhead Locker Accent Laminate
  • Black Ultraleather®
  • Flush-Mount Cabinet Hardware & Soft Close Doors
  • Froli® Ergonomic Bed Support System
  • High Gloss Laminate Cabinetry
  • LED 40″ Widescreen HDTV & Soundbar on Power Lift
  • Magic Suede® on Trim & Window Coverings
  • Marine Woven Synthetic Flooring
  • Multiplex Control System with 7″ Color Touchscreen
  • Pedestal Table (2)
  • Power Opening Sunroof Skylight with Screen & Shade
  • Power Tilting Oceanair Window Shades
  • Signature Aluminum Ceiling & Trim
  • Ultraleather® Seating
  • Villa® Power Sofa with Integrated Murphy Bed
  • Wardrobe Closet


  • Aluminum Refrigerator Fascia
  • Drop-In Waste Basket with Solid-Surface Cover
  • Fantastic® Fan with Temperature & Rain Sensors
  • Galley Extension Pull-Out Shelf
  • Kohler® Faucet & Sink with Flush Solid-Surface Cover
  • Solid-Surface Countertop with Aluminum Backsplash


  • Cedar Lined Wardrobe Closet
  • Corner Shower with Teak Wall Inlay
  • Fantastic® Fan with Temperature & Rain Sensors
  • Integrated LED Shower Lighting
  • Kohler® Faucet, Shower Head & Sink
  • Mirrored Medicine Cabinet
  • Riveted Aluminum Porthole Door
  • Storage Drawers
  • Toilet
  • Towel Rack


  • Azdel Composite Roof/Floor/Wall Material
  • Curved Composite Storage Doors with Continuous Hinge
  • Floor – Vacuum-Bonded Aluminum-Framed
  • Interlocking Extrusion Joints with Huck Rivets
  • Molded Fiberglass Front & Rear Caps
  • Roof – Fiberglass Crowned Vacuum-Bonded Aluminum-Framed
  • Trimless Smooth Fiberglass Body Seams
  • Walls – Radius Vacuum-Bonded Aluminum-Framed

Please see us for a complete list of features and available options!

All standard features and specifications are subject to change.


Airstream RV Logo

In 1931, Airstream began with Wally Byam’s dream: to build a travel trailer that would move like a stream of air, be light enough to be towed by a car, and create first-class accommodations anywhere.


Every inch of an Airstream has a function. Airstream is the most thoroughly tested brand in trailer history. Its engineering is the culmination of over 80 years of experience plus millions of miles on roads throughout the world.


With Airstream, there is no planned obsolescence. Airstreams of the Thirties are still on the road today, sturdy and modern as ever. They are intended as a lifetime investment in happiness.
